UHMWPE Chemical Anti-static Discharge Hose

The UHMWPE Chemical Anti-static Discharge Hose is specifically designed for the safe transfer of a wide range of aggressive chemicals while incorporating anti-static properties to prevent the accumulation of static electricity. This hose is ideal for industrial applications involving the handling of corrosive liquids, acids, solvents, and other hazardous materials, ensuring both safety and efficiency during discharge operations.

1. Construction

• • Inner Liner: Made from Ultra-High-Molecular-Weight Polyethylene (UHMWPE), the inner liner provides excellent chemical resistance against a wide array of corrosive substances, including strong acids, bases, and organic solvents. The smooth surface minimizes friction, allowing for efficient flow.
  • Anti-static Properties: The hose is engineered with anti-static additives in the liner to dissipate static electricity, reducing the risk of sparks and fires during chemical transfer.

• Reinforcement: The hose features multiple layers of high-tensile synthetic cords or textile plies that provide strength and flexibility while maintaining the ability to withstand high working pressures.
• Outer Cover: The outer cover is constructed from abrasion-resistant synthetic rubber, offering protection against environmental factors, including UV exposure, ozone, and mechanical wear.

2. Standard Sizes

• Inner Diameter: Available in a range of sizes from 1 inch (25mm) to 8 inches (200mm), accommodating various flow rates and industrial needs.
• Length: Standard lengths typically range from 10 meters to 20 meters, with custom lengths available to meet specific operational requirements.

3. Working Pressure

• The hose is designed to handle medium to high-pressure discharge applications, with a typical working pressure range of 10 to 16 bars (145 to 232 psi), depending on the size and construction.

4. Temperature Range

• Suitable for operating in a wide temperature range, typically from -40°C to 80°C (-40°F to 176°F), allowing for use in diverse environments and conditions.

5. End Fittings

• Equipped with corrosion-resistant end fittings, such as stainless steel or polypropylene, ensuring secure and leak-free connections for chemical discharge. The fittings can be flanged, threaded, or camlock type based on application needs.
• Fittings are designed to resist corrosion from chemicals, ensuring durability and safety during operations.

6. Performance Characteristics

• Chemical Resistance: The UHMWPE liner provides superior chemical resistance, allowing the hose to handle a wide variety of aggressive chemicals, including acids, bases, and solvents.
• Anti-static Feature: The incorporation of anti-static properties minimizes the risk of static buildup, enhancing safety during the transfer of flammable or hazardous liquids.
• Abrasion Resistance: The outer cover protects against external abrasion, ensuring the hose remains intact and functional even in challenging industrial environments.
• Flexibility: The hose maintains excellent flexibility, making it easy to handle and maneuver during chemical discharge operations.

7. Applications

• Ideal for the discharge of aggressive chemicals, acids, solvents, and hazardous liquids in industrial settings such as chemical plants, refineries, and manufacturing facilities.
• Suitable for chemical tank trucks, bulk chemical transfer systems, and other applications requiring safe discharge of chemicals.
• Frequently used in environments where static discharge poses a risk, making it ideal for handling flammable liquids and reactive chemicals.

8. Certifications

The manufacturer of the products supplied by Precision Hoses Pty Ltd is certified under the ISO 9001:2008 Quality Management System, ensuring a consistent commitment to quality. Additionally, the manufacturer’s products have achieved key industry certifications, including the BV Certificate, CE Certificate, ECM Certificate, and CCS Certificate, awarded in 2010. These certifications highlight the exceptional standards of the products we resell, providing our customers with confidence in their reliability and performance.

The UHMWPE Chemical Anti-static Discharge Hose is a reliable and safe solution for the transfer of aggressive chemicals, combining superior chemical resistance, anti-static properties, and flexibility to meet the demands of various industrial applications. Its robust construction and anti-static features ensure enhanced safety and efficiency during chemical discharge operations.
